霍尼韦尔RAEGuard 3固定点型氧气气体探测器RAEGuard 3 /FGM-6300/FGM-6300S固定式工业及商业用途点型有毒气体探测器是应用于危险环境中的防爆产品,请在安装、操作及维护中确保该产品的整体隔爆性能,并严格遵守产品使用地所在地区的相关规定。为避免电击或可能引起的BZ危险,在危险环境中对仪器进行任何开盖操作前请先关闭电源,只有在确认周围环境安全的情况下,才可以对仪器进行开盖维护、操作。
RAEGuard 3 /FGM-6300/FGM-6300S氧气探测器安装前当你收到探测器后,应该首先对照仪器包装箱中的“包装清单”,对照你所订购的仪器及其配件是否正确。包装箱中标准清单其中,本地声光报警器会随探测器一起放置在包装箱中,但是请注意:防雷模块和蓝
牙模块会直接被安装在探测器中,继电器模块和 HART 模块会包含在 PCB 电路板上。RAEGuard 3 气体探测器还为用户提供更多配件,方便您的不同应用,它们将于探测器分开发货,也请核对:
RAEGuard 3 /FGM-6300/FGM-6300S氨气探测器尺寸为了满足用户的多样应用环境及需求,RAEGuard 3 提供丰富多样的附件,物理尺寸不包括配接其他附件,仅含变送器、传感器及遮阳罩等基本单元。
RAEGuard 3 /FGM-6300/FGM-6300S有毒气体探测器可检测气体:
可燃气 - CH4, 0-100%LEL
红外 - CH4, 0-100%LEL
红外 - CO2, 0-5%vol(1%vol to 5%vol)
O2, 0-30%vol
H2S, 0-100ppm (20 to 200ppm)
CO, 0-500ppm (50 to 1000ppm)
H2, 0-1000ppm only
H2S, 0-30ppm (20 to 200ppm)
H2S, 0-50ppm (20 to 200ppm)
H2S, 0-150ppm (20 to 200ppm)
H2S, 0-200ppm (20 to 200ppm)
H2S, 0-20ppm (20 to 200ppm)
CO, 0-50ppm (50 to 1000ppm)
CO, 0-100ppm (50 to 1000ppm)
CO, 0-200ppm (50 to 1000ppm)
CO, 0-300ppm (50 to 1000ppm)
C3H3N-H, 0-100ppm (10 to 100ppm)*
Cl2-L, 0-5ppm (1 to 5ppm)
ClO2, 0-1ppm only*
PH3, 0-5ppm (5 to 20ppm)
COCl2, 0-1ppm only*
HCHO, 0-50ppm (10 to 50ppm)*
NH3, 0-100ppm (20 to 100ppm)
NH3-H, 0-500ppm (200 to 1000ppm)
Cl2, 0-10ppm (5 to 50ppm)
NO, 0-100ppm (50 to 250ppm)*
NO2, 0-20ppm (10 to 50ppm)
HCl, 0-30ppm (10 to 30ppm)
HCN, 0-30ppm (10 to 50ppm)
ETO, 0-100ppm (10 to 100ppm)
C3H3N, 0-10ppm (4 to 20ppm)
C2H3Cl, 0-100ppm (10 to 100ppm)
CH4O, 0-100ppm (20 to 100ppm)*
SO2, 0-20ppm (10 to 50ppm)
